VIBMASSS

by Gregory Spaulding
(Washington, DC USA)

VIBMASSS

VIBMASSS

Until now electromagnetic EMF sources were not mentioned as a renewable energy sources. Until now electromagnetic apparatuses using relative motion between helical or toroidal solenoids and a permanent ferromagnetic for EMF generation was produced by transduction of external iterative mechanical motion.


VIBMASSS iteratively diverts flux fields of direction to create relative motion and uses dual chambers or more paring for EMF output and electromagnet continued operation simultaneously.

VIBMASSS principle for continuous autonomous voltage production is that a permanent ferromagnet with static flux loops emanating from its poles produces the inducing perpendicular force need for EMF creation from the interacting closed looped solenoid.

If you combine sub component ferromagnet’s (smaller dipole magnets) into a single larger toroidal (concentric oval loop) unit, whether electromagnetic or permanent or combination, there will be no external static flux loops emanations, only lines of flux in the inner core.

So, by creating a stimulated concentric magnetic flux loop δβ= βMax- β0 relative to the external solenoid (NA) divided by δt.

VIBMASSS Voltage Induced Balanced Magnetic Attraction Spontaneous/Stimulated Switching. The VIBMASSS is a balanced oscillator of relative flux motion between a permanent ferromagnetic core and solenoid creating EMF using dual or greater pairings.

The permanent ferromagnetic for diagramming reference has vertical orientation along with vertical flux loops emanations. The flux flow oscillations is between the larger unified concentric Electromagnet/Permanent Magnet loop, which is the stimulated, and the individual Permanent Magnet of the EMF Chamber, which is the spontaneous.

I will continue the concept of, no external sustained EMF or mechanical motion assistance (NESEMMA) for magnetic flux energy apparatuses, created for the ALEEG apparatus.

The size of the apparatus can be a large industrial unit or nano size unit, with the creation and improvements of rare earth magnets and now Nano Spintronics.

VIBMASSS only needs a one-time initial start by applying EMF to only the electromagnets to start the initial stimulated cycle and it will continue with constant EMF output except for component failure (CEOECF).

EMF=-(NA)δβ/δt, the iterative flux deviation between the Permanent Ferromagnetic (PM) and solenoid for induced voltage output. The PM has cylindrical body with dual ends conic geometry of the same length and fit within the diameter of the solenoid.

A constant ∟90∘ or cos θ 90∘ between PM and solenoid, constant Area ∏r² (A), and number of loops (N). To determine the needed Wb/m ² or Tesla, which is the uniform parameter for all pairings, determine the output EMF or voltage that will be the voltage or EMF for all PM’s and substitute that value into the EMF formula to determine Wb/m ² or Tesla for βMax.

To determine the voltage of the Electromagnets (EM) and the length of separation from the PM’s use F= μqm1(qm2)/4∏r² which determines the minimal attractive force between EM and PM to divert magnetic flux direction from poles to EM’s flux field core once EMF or voltage is applied to the EM which is voltage doubled if needed.
